Program 37 — AUTO PAN
This effect performs automatic panning across the stereo image.
Parameter Setting Range Description
Freq. 0.5Hz 0.1–40.0Hz Modulation frequency.
LR Depth 98% 0–100% Left to right pan depth.
FR Depth 15% 0–100% Front to rear pan depth.
LSF F 140Hz 32Hz–1.0kHz Low shelving filter frequency.
LSF G +4dB –12 to +12dB Low shelving filter gain.
Dir. L<–>R Pan direction Choose from L<–>R, L-->R, L<--R, Turn L, or Turn R.
EQ F 630Hz 160Hz–8.0kHz Equalizer frequency.
EQ G +3dB –12 to +12dB Equalizer signal gain.
HSF F 3.2kHz 1.0–10.0kHz High shelving filter frequency.
HSF G 0dB –12 to +12dB High shelving filter gain.
Program 38 — PHASING
Stereo phaser. This effect simulates old phase shifter effects.
Parameter Setting Range Description
Freq. 1.3Hz 0.1–40.0Hz Modulation frequency.
Depth 52% 0–100% Modulation depth.
FB.Gain +68% –99 to +99% Feedback gain. The amount of signal returned to the effect.
Offset 32 0–100 Phase offset. The amount that the signal phase is offset.
Stage 4 4, 6, 8 Stage of phase.
LSF F 250Hz 32Hz–1.0kHz Low shelving filter frequency.
LSF G +2dB –12 to +12dB Low shelving filter gain.
HSF F 3.6KHz 1.0–10.0kHz High shelving filter frequency.
HSF G +1dB –12 to +12dB High shelving filter gain.
Program 39 — ST.PITCH CHANGE
Two-part stereo pitch shifter. This stereo effect changes the pitch of the left and right channels independently of each
other.
Parameter Setting Range Description
Pitch 0 –12 to +12 Coarse pitch change for pitch changers 1 and 2.
Fine(1) +20 –50 to +50 Fine pitch for pitch changer 1.
Fine(2) –20 –50 to +50 Fine pitch for pitch changer 2.
Out(1) +100 –100 to +100 Output volume level for pitch changer 1.
Out(2) +100 –100 to +100 Output volume level for pitch changer 2.
Pan(1) L100 L100–R100 Pan control for pitch changer 1.
Pan(2) R100 L100–R100 Pan control for pitch changer 2.
FB.G(1) +28% –99 to +99% Feedback gain for pitch changer 1.
FB.G(2) –28% –99 to +99% Feedback gain for pitch changer 2.
Delay 25.0ms 0.1–255.0ms Delay time before the feedback starts.
