Specifications 243
02R User’s Guide
Pan 33 positions (L = 16 to 1, C, R = 16 to 1 )
Routing BUS 1 through 8. ST. DIRECT
Solo
ON/OFF
Pre fader / After pan
Meter
Peakhold: ON/OFF
12 points displays of the pre-EQ / post-EQ / post-fader levels of all channel input
are displayed on the screen.
Tape Input channel (TAPE 1 through 16)
I/O option
ANALOG, ADAT, TASCAM, AES/EBU, YAMAHA
Filter
DC cut filter / de-emphasis
Attenuator
0 to 96 dB (1 dB step)
4 band parametric
equalizer
(Parameters are the same as MIC/LINE input equalizer.)
Dynamics
(Parameters are the same as MIC/LINE input dynamics.)
Delay
0 to 2600 sample
Phase
NORMAL / REVERSE
ON/OFF
Fader
Rotary encoder
INPUT / AUX1 / AUX2 / AUX3 / AUX4 / AUX5 / AUX6 / AUX7 / AUX8
Aux send
(Parameters are the same as MIC/LINE input aux send.)
Pan
33 positions ( L = 16 to 1, C, R = 16 to 1)
Routing
BUS 1 through 8. ST
Solo
ON/OFF
Pre fader / After pan
Meter
Peakhold: ON/OFF
12 points displays of the pre-EQ / post-EQ / post-fader levels of all channel input
are displayed on the screen.
Effect Return (EFF 1 through 2)
Attenuator 0 to 96 dB (1 dB step)
4 band parametric
equalizer
(Parameters are the same as MIC/LINE input equalizer.)
Delay 0 to 2600 sample
Phase NORMAL / REVERSE
ON/OFF
Fader
Rotary encoder
INPUT / AUX1 / AUX2 / AUX3 / AUX4 / AUX5 / AUX6 / AUX7 / AUX8
Aux send
(Parameters are the same as MIC/LINE input aux send. EFF1 can only send to
AUX8. EFF2 can only send to AUX7.)
Pan 33 positions (L = 16 to 1, C, R = 16 to 1)
Input channel (MIC/LINE 1 through 24)
