244 Specifications
02R User’s Guide
Outputs
Routing BUS 1 through 8. ST
Solo
ON/OFF
Pre fader / After pan
Meter
Peakhold: ON/OFF
12 points displays of the pre-EQ / post-EQ / post-fader levels of all channel input
are displayed on the screen.
STEREO OUT
Dynamics (parameters are the same as MIC/LINE input dynamics.)
4 band parametric
equalizer
(parameters are the same as MIC/LINE input equalizer.)
Fader 100 mm motorized
ON/OFF
Meter 21-elements x 2 LED meter. (pre fader / post fader)
D/A converter 20bit linear / 8 times oversampling
BUS OUT (BUS1 through BUS8)
Dynamics (parameters are the same as MIC/LINE input dynamics.)
Level rotary encoder
Meter
12 points displays of the pre/post fader levels of all channel input are displayed
on the screen.
I/O option ANALOG, ADAT, TASCAM, AES/EBU, YAMAHA
AUX OUT (AUX1 through AUX8)
Level rotary encoder
Meter
12 points displays of the pre/post fader levels of all channel input are displayed
on the screen.
D/A converter 18bit linear / 8 times oversampling (AUX1 through AUX6)
CONTROL ROOM MONITOR OUT
Select switch 2TR-A1 / 2TR-A2 / 2TR-D1 / 2TR-D2 / 2TR-D3 / AUX5 /AUX6 / ST
Mono ON/OFF
DIM ON/OFF
D/A converter 20bit linear / 8 times oversampling
Emphasis Auto ON/OFF
Level control
Phone level
Effect Return (EFF 1 through 2)
