37
RX-V1800/HTR-6190/DSP-AX1800
RX-V1800/HTR-6190/
DSP-AX1800
原因:パワーアンプに過電流が流れた。
補足:パワートランジスタの電流を検出していますので、
電流検出トランジスタをチェックすれば異常チャン
ネルが特定できます。
異常状態のままパワーオンすると、瞬時にプロテクション
がかかり、すぐに電源が切れます。
When there is a history of protection function: プロテクション履歴がある場合:
Display provided when Self-Diagnostic
Function started
The FL display of the main unit displays the protection
function history data and the version (1 alphabet) then the
main menu (sub-menu MARGIN of main menu No. 1 DSP
THROUGH) a few seconds later.
When there is no history of protection function:
ダイアグ起動時の表示
本機のFLディスプレイにプロテクション履歴情報とバー
ジョン(英1文字)が表示され、数秒後にメインメニュー
(No.1DSPTHROUGHのサブメニューMARGIN)になりま
す。
プロテクション履歴がない場合:
Cause: An excessive current flowed through the power
amplifier.
Suppleementary information: As current of the power
transistor is detected, the abnormal channel can be
identified by checking the current detect transistor.
Turning on the power without correcting the abnormality
will cause the protection function to work immediately and
the power supply will instantly be shut off.
After a few seconds / 数秒後
Main menu display / メインメニュー表示Opening message / オープニング表示
When there is no protection history
プロテクション履歴が無い場合
過電流によるプロテクション履歴がある場合When there is a history of protection function due
to excess current
When there is a history of protection
function due to excess current
過電流によるプロテク
ション履歴がある場合
注意!
異常状態のまま本機の電源を入れると、危険な状態に
なり、さらに回路が損傷を受ける原因になります。そ
のため連続してプロテクションが働いた場合、3回目
以降MASTERON/OFFキーを押しても電源が入らな
くなります。再度電源を入れる場合、一度本機の電源
コードをAC電源コンセントから抜いて接続し直してく
ださい。
本機の電源をいれる前に、各アンプのチャンネル内の
出力トランジスタに損傷がないかチェックしてくださ
い。
アンプの電流は、各チャンネルのエミッターの抵抗器
間電圧を測定することによりモニターしてください。
Note)
Applying the power to the main unit without cor-
recting the abnormality can be dangerous and
cause additional circuit damage. To avoid this, if
protection function has been activated 3 times
continuously, the power will not turn on even
when the “MASTER ON/OFF” key is pressed. In
order to turn on the power again, disconnect the
power cable of the main unit from the AC outlet
once and then reconnect it again.
The output transistors in each amplifier channel
should be checked for damage before applying
power of the main unit.
Amplifier current should be monitored by measur-
ing DC voltage across the emitter resistors for
each channel.
DIAGNOSTIC 1.DSP THROUGH
MARGIN
DIAGNOSTIC
I PROTECT
