– 18 –
BRKT
E
STEERING HANDLE (OPTION)
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
19 Nut 1
20 Engine stop lanyard switch 1
21 Screw 2
22 Shift lever cover 1
23 Bolt 1
24 Shift lever 1
25 Bushing 1
26 Steering handle sub assembly 1
Reverse the disassembly steps for
assembly.
