Yamaha F80A - Page 52

– 20 –
BRKT
E
STEERING HANDLE (OPTION)
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
11 Friction piece 1
12 Frame 1
13 Clip 1
14 Shift cable 1 Longer cable
15 Throttle arm shaft 1
16 Throttle arm 1
17 Screw 2
18 Spring housing 1
19 Roller 1
20 Actuator 1
21 Spring 1
22 Shift arm 1
