Yamaha FZS1000(N) 2001 User Manual

4-3
FRONT WHEEL AND BRAKE DISCS
CHAS
WARNING
NOTE:
NOTE:
NOTE:
NOTE:
EAS00521
REMOVING THE FRONT WHEEL
1. Stand the motorcycle on a level surface.
Securely support the motorcycle so that
there is no danger of it falling over.
Place the motorcycle on a suitable stand so that
the front wheel is elevated.
2. Remove:
 left brake caliper
 right brake caliper
Do not squeeze the brake lever when removing
the brake calipers.
3. Elevate:
 front wheel
Place the motorcycle on a suitable stand so that
the front wheel is elevated.
EAS00523
DISASSEMBLING THE FRONT WHEEL
1. Remove:
 oil seals
 wheel bearings
a. Clean the outside of the front wheel hub.
b. Remove the oil seals
1
with a flat-head
screwdriver.
To prevent damaging the wheel, place a rag
2
between the screwdriver and the wheel surface.
c. Remove the wheel bearings with a general
bearing puller.

Yamaha FZS1000(N) 2001 Specifications

General

Displacement	998 cc
Bore x Stroke	74.0 mm x 58.0 mm
Compression Ratio	11.4:1
Fuel System	Fuel Injection
Transmission	6-speed
Seat Height	820 mm
Fuel Capacity	21 liters
Rear Suspension	Swingarm (link suspension)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	1, 450 mm
Dry Weight	208 kg
Final Drive	Chain
Frame	Aluminium Deltabox
Starter	Electric
Engine Type	Liquid-cooled, 4-stroke, DOHC, 5-valve, inline-4
Power	143 hp @ 10, 000 rpm
Torque	106 Nm @ 7, 500 rpm
Ignition	Digital TCI
Front Suspension	Telescopic fork
Front Brake	Double disc, Ø 298 mm
Rear Brake	Single disc, Ø 245 mm
Ground Clearance	140 mm
Valves	20 valves
