4-9
REAR WHEEL AND BRAKE DISC
CHAS
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
Removing the rear wheel
Brake caliper
Brake torque rod
Nut
Washer
Wheel axle
Rear wheel assembly
1
1
1
1
1
1
Remove the parts in the order listed.
Place the motorcycle on a suitable stand
so that the rear wheel is elevated.
Loosen.
For installation, reverse the removal
procedure.
NOTE:
150 Nm (15 mkg)
40 Nm (4.0 mkg)
EAS00551
REAR WHEEL AND BRAKE DISC
REAR WHEEL
