Yamaha FZS1000(N) 2001 User Manual

9-3
TROUBLESHOOTING
TRBL
SHTG
FUEL SYSTEM
Carburetor(s)
 Faulty diaphragm
 Incorrect fuel level
 Loose or clogged main jet
Fuel pump
 Faulty fuel pump
JUMPS OUT OF GEAR
Shift shaft
 Incorrect shift pedal position
 Improperly returned stopper lever
Shift forks
 Worn shift fork
Shift drum
 Incorrect axial play
 Worn shift drum groove
Transmission
 Worn gear dog
EAS00848
POOR MEDIUM-AND-HIGH-SPEED PERFORMANCE
Refer to “STARTING PROBLEMS”.
ENGINE
Air filter
 Clogged air filter element
EAS00850
FAULTY GEAR SHIFTING
SHIFTING IS DIFFICULT
Refer to “CLUTCH DRAGS”.
SHIFT PEDAL DOES NOT MOVE
Shift shaft
 Improperly adjusted shift rod
 Bent shift shaft.
Shift drum and shift forks
 Foreign object in a shift drum groove
 Seized shift fork
 Bent shift fork guide bar
Transmission
 Seized transmission gear
 Foreign object between transmission
gears
 Improperly assembled transmission

Yamaha FZS1000(N) 2001 Specifications

General

Displacement	998 cc
Bore x Stroke	74.0 mm x 58.0 mm
Compression Ratio	11.4:1
Fuel System	Fuel Injection
Transmission	6-speed
Seat Height	820 mm
Fuel Capacity	21 liters
Rear Suspension	Swingarm (link suspension)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	1, 450 mm
Dry Weight	208 kg
Final Drive	Chain
Frame	Aluminium Deltabox
Starter	Electric
Engine Type	Liquid-cooled, 4-stroke, DOHC, 5-valve, inline-4
Power	143 hp @ 10, 000 rpm
Torque	106 Nm @ 7, 500 rpm
Ignition	Digital TCI
Front Suspension	Telescopic fork
Front Brake	Double disc, Ø 298 mm
Rear Brake	Single disc, Ø 245 mm
Ground Clearance	140 mm
Valves	20 valves
