8-5
EBU00614
Panel removal and installation
The panels illustrated need to be removed to
perform some of the maintenance described
in this chapter.
Refer to this section each time a panel has to
be removed or reinstalled.
1. Panel A 2. Panel B
1. Panel C 2. Panel D
3. Panel E 4. Panel F
U5VH10.book Page 5 Thursday, May 16, 2002 2:18 PM
