6-4
EBU01225
Drive select lever operation and reverse
driving
CAUTION:
_
Before shifting, you must stop the ma-
chine and return the throttle lever to its
closed position. Otherwise, the transmis-
sion may be damaged.
_
Shifting: forward
1. Bring the machine to a complete stop
and return the throttle lever to the closed
position.
2. Shift the gear from neutral to forward and
vice versa by moving the drive select le-
ver along the shift guide.
NOTE:
_
Make sure that the drive select lever is com-
pletely shifted into position.
_
1. Drive select lever
3. Open the throttle lever gradually.
U5VH10.book Page 4 Thursday, May 16, 2002 2:18 PM
