4-13
1. Arrow mark pointing to “RES”
EBU00095
Starter (choke) “”
Starting a cold engine requires a richer air-fuel
mixture. A separate starter circuit supplies this
mixture.
Move in direction
a
to turn on the starter
(choke).
Move in direction
b
to turn off the starter
(choke).
Refer to “Starting a cold engine” for proper op-
eration. (See page 6-1.)
1. Starter (choke) “”
RES Position
