4-8
EBU00070
Front brake lever
The front brake lever is located on the right
handlebar. Pull it toward the handlebar to ap-
ply the front brake.
1. Front brake lever
EBU00073
Rear brake pedal and lever
The brake pedal is located on the right side of
the machine and the brake lever is located on
the left handlebar. Push down on the pedal or
pull the lever toward the handlebar to apply
the rear brake.
1. Brake pedal
1. Rear brake lever
U5VH10.book Page 8 Thursday, May 16, 2002 2:18 PM
