To install
1. Place the panel in the original position
and install the quick fasteners.
2. Install the front carrier and the bolts, then
tighten to the specified torque.
EBU01013
Panel E
To remove
Remove the bolts, and then take the panel off.
To install
Place the panel in the original position, and
then install the bolts.
1. Panel E 2. Bolt (× 3)
Tightening torque:
Carrier bolts:
19 Nm (1.9 m·kgf, 13 ft·lbf)
