8-18
CAUTION:
_
Be sure no foreign material enters the final
gear case.
_
7. Install the oil filler bolt.
8. Check for oil leakage. If oil leakage is
found, check for the cause.
9. Install the final gear case cover bolts, and
then tighten them to the specified torque.
Recommended oil:
See page 5-7.
Oil quantity:
0.19 L (0.17 Imp qt, 0.20 US qt)
Tightening torque:
Final gear case cover bolt:
16 Nm (1.6 m·kgf, 12 ft·lbf)
U5VH10.book Page 18 Thursday, May 16, 2002 2:18 PM
