8-21
1. Place the ATV on a level surface.
2. Remove panels E and F. (See pages 8-10
and 8-11 for panel removal and installa-
tion procedures.)
3. Place a container under the engine, and
then remove the coolant drain bolt. (Use
a trough or a similar object as shown to
prevent coolant from spilling on the foot-
rest.)
1. Coolant drain bolt
1. Trough
4. Remove the front carrier and panel C.
(See page 8-9 for removal and installa-
tion procedures.)
