Yamaha MOX6 Service Manual

72
MOX6/MOX8
039 SW&LED Check Start of test A0 4B 00 Test End: A0 4B 04
on PCB PNB
[PANEL B (Sw)] Other codes are same as T-No.13
040 SW&LED Check Start of test A0 4C 00 Test End: A0 4C 04
on PCB PNC
[PANEL C (Sw)] Other codes are same as T-No.13
041 Encoder Check Start of test A0 4D 00 OK: A0 4D 02
on PCB PNA
[PANEL A (Enc)]
042 Encoder Check Start of test A0 4E 00 OK: A0 4E 02
on PCB PNB
[PANEL B (Enc)]
043 Auto Power Off Start of test A0 4F 00 -
[Power Off]
044 Output Full Level R Start of test A0 5A 00 -
[Output Full R]
045 Output Full Level L Start of test A0 5B 00 -
[Output Full L]
046 Factory Set Start of test A0 54 00 -
[Factory Set]
047 Test Exit Exit from Test Mode A0 56 00 -
[Test Exit]
Test Test Item Operation MIDI Reception Code MIDI Send Back Code
No. [Displayed Name]

Yamaha MOX6 Specifications

General

Keyboard	61 keys, semi-weighted
Wave ROM	355MB
Sound Engine	AWM2
Drum Kits	64
Arpeggiator	6, 720 types
Display	240 x 64 dot backlit LCD
Weight	7.0 kg
Effects	Reverb, Chorus, Insertion Effects, Master Effect, Part EQ
Sequencer	16-track, 226, 000 notes
Connectivity	USB, MIDI (In/Out/Thru), Phones, Output (L/Mono, R), Foot Controller, Foot Switch, DC In
Polyphony	64 voices
Preset Voices	1, 024 Normal Voices + 64 Drum Kits
Dimensions	1, 030 x 358 x 125 mm
