71
MOX6/MOX8
017 Orange LED On Start of test A0 26 00 -
[Orange LED On]
018 LCD All On Start of test A0 27 00 -
[LCD On]
019 LCD All Off Start of test A0 28 00 -
[LCD Off]
020 Slider Start of test A0 51 00 OK: A0 51 02
[Slider]
021 Encoder Start of test A0 50 00 OK: A0 50 02
[Encoder]
022 Pitch Bend Start of test A0 33 00 Max OK: 91 3C 7F - 91 3C 00
[Pitch Bend] Min OK: 91 43 7F - 91 43 00
Center OK: 91 48 7F - 91 48 00
OK: A0 33 02
023 Modulation Wheel Start of test A0 52 00 Max OK: 91 3C 7F - 91 3C 00
[Modulation] Min OK: 91 43 7F - 91 43 00
OK: A0 52 02
024 Foot Controller Start of test A0 2D 00 Max OK: 91 3C 7F - 91 3C 00
[Foot Controller] Min OK: 91 43 7F - 91 43 00
OK: A0 2D 02
025 Foot SW Start of test A0 2E 00 Max OK: 91 3C 7F - 91 3C 00
[FootSw (Assign)] Min OK: 91 43 7F - 91 43 00
OK: A0 2E 02
026 Sustain Pedal Start of test A0 2F 00 Max OK: 91 3C 7F - 91 3C 00
[Sustain] Min OK: 91 43 7F - 91 43 00
OK: A0 2F 02
027 A/D Input (Mic) Start of test A0 40 00 -
[Mic Input]
028 A/D Input (Line) Start of test A0 53 00 -
[Line Input]
030 USB Connect Check Start of test A0 57 00 OK: A0 57 02
[USB Connect] NG: A0 57 03
031 USB to Host Start of test A0 59 00 -
[USB Function]
032 USB to Device Start of test A0 58 00 OK: A0 58 02
[USB Storage]
033 Keyboard Start of test A0 3B 00 16N: A0 3B 01 (MOX6)
[KeyBoardType] GHS: A0 3B 02 (MOX8)
NG: A0 3B 03
034 ROM Full Check Start of test A0 41 00 OK: A0 41 02
[ROM 2 (Full)] NG: A0 41 03
035 RAM Full Check Start of test A0 42 00 OK: A0 42 02
[RAM 2 (Full)] NG: A0 42 03
036 Wave ROM Full Check Start of test A0 45 00 OK: A0 45 02
[WaveROM 2(Full)] NG: A0 45 03
037 FX RAM Full Check Start of test A0 47 00 OK: A0 47 02
[FX RAM 2(Full)] NG: A0 47 03
038 SW&LED Check Start of test A0 4A 00 Test End: A0 4A 04
on PCB PNA
[PANEL A (Sw)] Other codes are same as T-No.13
Test Test Item Operation MIDI Reception Code MIDI Send Back Code
No. [Displayed Name]
