70
MOX6/MOX8
The USB and MIDI terminals are available as the command input port for the test code entry.
Asforothercommands,onlytheMIDIterminalisavailableastheinputport.
- Test Mode Entry Entry to Test Mode F0 43 73 01 60 00 F7 -
001 Version Start of test A0 01 00 Output Start
[Version] F0 43 73 01 68 00 00 00 00 F7
Version No.(Boot)
F0 43 73 01 68 01 V1 V2 V3 F7
Version No.(Firm)
F0 43 73 01 68 02 V1 V2 V3 F7
Output End
F0 43 73 01 68 00 00 00 7F F7
V1,V2,V3: Version No.(ASCII)
002 ROM Simple Check Start of test A0 03 00 OK: A0 03 02
[ROM 1] NG: A0 03 03
003 RAM Simple Check Start of test A0 04 00 OK: A0 04 02
[RAM 1] NG: A0 04 03
004 Wave ROM Simple Check Start of test A0 06 00 OK: A0 06 02
[Wave ROM 1] NG: A0 06 03
005 FX RAM Simple Check Start of test A0 0C 00 OK: A0 0C 02
[FX RAM 1] NG: A0 0C 03
006 All Memory Simple Check Start of test A0 18 00 OK: A0 18 02
[All Memory] NG: A0 18 03
007 Tone Gererator Check Start of test A0 10 00 -
[TG]
008 Pitch Accuracy Start of test A0 13 00 -
[Pitch]
009 Output Level R Start of test A0 14 00 -
[Output R]
010 Output Level L Start of test A0 15 00 -
[Output L]
011 Digital Mute Start of test A0 1F 00 -
[Line Out Mute] Mute Off A8 00 00 -
Mute On A8 00 01 -
012 Analog Mute Start of test A0 20 00 -
[Mute] Mute Off A8 00 00 -
Mute On A8 00 01 -
013 SW&LED Check Start of test A0 22 00 Detection of SW On: 91 nn 0F
[SW, LED] Detection of SW Off: 91 nn 00
nn: Corresponding Code to SW
(See "SW Test Item List" (Page 86) for
more details.)
Test End: A0 22 04
014 All LED On Start of test A0 23 00 -
[All LED On]
015 Red LED On Start of test A0 24 00 -
[Red LED On]
016 Green LED On Start of test A0 25 00 -
[Green LED On]
Test Test Item Operation MIDI Reception Code MIDI Send Back Code
No. [Displayed Name]
6. Test Item List (MIDI Mode)
To Next Page
