4-41
REAR BRAKE
Removing the rear brake caliper
Order Job/Parts to remove Q’ty Remarks
Brake fluid
Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM (ABS)” on page 3-15.
1 Brake hose union bolt 1
2 Brake hose gasket 2
3 Brake hose 1
4 Rear brake caliper 1
LT
S
S
New
1
3
4
2
30 N・m (3.0 kgf・m, 22 lb・ft)
22 N
•
m (2.2 kgf
•
m, 16 lb
•
ft)
T
.R.
27 N
•
m (2.7 kgf
•
m, 20 lb
•
ft)
T
.R.
