4-79
REAR SHOCK ABSORBER ASSEMBLY
Removing the rear shock absorber assembly (for MTN890D)
Order Job/Parts to remove Q’ty Remarks
1 Rear shock absorber assembly lower nut/Bolt 1/1
2
Rear shock absorber assembly upper nut/
Washer/Bolt
1/1/1
3 Bracket 1
4 Gas cylinder bracket 1
5 Rear shock absorber assembly 1
6 Relay arm nut/Bolt 1/1
7 Connecting arm upper nut/Bolt 1/1
8 Relay arm 2
9 Connecting arm lower nut/Bolt 1/1
10 Connecting arm 1
11 Collar/Oil seal/Bearing 1/2/1
12 Collar/Oil seal/Bearing 1/2/1
13 Collar/Oil seal/Bearing 1/2/1
14 Collar/Oil seal/Bearing 1/2/1
15 Collar 1
1
8412
11
1
8
6
7
2
9
12
11
6
7
5
2
13
13
10
14
14
15
9
3
LS
LT
LS
LS
LS
New
New
New
LS
New
New
44 N
•
m (4.4 kgf
•
m, 32 lb
•
ft)
T
.R.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T
.R.
44 N
•
m (4.4 kgf
•
m, 32 lb
•
ft)
T
.R.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T
.R.
44 N
•
m (4.4 kgf
•
m, 32 lb
•
ft)
T
.R.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T
.R.
LS
