Yamaha QL5 Service Manual

50
QL5/QL1
IC131 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC151 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC181 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC251 X7911A00 IC NJU7043RB1(TE1)
ＩＣ
OP AMP 03
IC252 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC281 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC301 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC401 X9044A00 IC TC7SZ07FU(TE85L,F)
ＩＣ
BUFFER 01
IC402 YD513A00 IC LM5575MHX/NOPB
ＩＣ
SWITCHING REGULATOR 06
IC431 X8375A00 IC TC7SHU04FU
ＩＣ
INVERTER
IC432 X9044A00 IC TC7SZ07FU(TE85L,F)
ＩＣ
BUFFER 01
IC433 X9395A00 IC LM5576MHX/NOPB
ＩＣ
SWITCHING REGULATOR 07
IC451 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC481 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC511 X4365A0R IC LM2940CSX-15/NOPB
ＩＣ
REGULATOR +15V 03
IC521 X3949A0R IC LM2990SX-15/NOPB
ＩＣ
REGULATOR -15V 06
IC531 X9037A00 IC LM1085ISX-5.0/NOPB
ＩＣ
REGULATOR +5V 05
IC541 XN086A00 IC NJM79L05UA(TE1)
ＩＣ
REGULATOR -5V
IC551 YA632A00 IC LM5001MA/NOPB
ＩＣ
REGULATOR +48V 06
IC601 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
*
IC631 YF492A00 IC TPS54260DGQR
ＩＣ
SWITCHING REGULATOR
IC651 X4368A0R IC NJM78M20DL1A(TE1)
ＩＣ
REGULATOR +20V 02
IC661 YE140A00 IC NJM2386ADL3-05(TE2)
ＩＣ
REGULATOR +5V 02
IC671 X4367A0R IC LM2990SX-5.0/NOPB
ＩＣ
REGULATOR -5V 05
IC701 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
IC731 YE497A00 IC TPS54240DGQR
ＩＣ
SWITCHING REGULATOR 05
K001 -- EARTH PLATE
アースプレート
(WA20680)
K002 -- EARTH PLATE
アースプレート
(WA20680)
*
L101 ZJ245700 COIL CER1277B-100M-RB
コイル
L131 WF468000 INDUCTANCE (CHIP) 22uH 7E10H-220
チップインダクタ
02
L151 WF468000 INDUCTANCE (CHIP) 22uH 7E10H-220
チップインダクタ
02
L181 WF468000 INDUCTANCE (CHIP) 22uH 7E10H-220
チップインダクタ
02
L251 WH145900 COIL
100uH CDRH127/LDNP-101MC
コイル１００Ｕ
03
L281 WZ873300 INDUCTANCE (CHIP) CER7052-220M-R
チップインダクタ
01
*
L301 ZJ273900 INDUCTANCE (CHIP) 22.0uH CER8065B-220
チップインダクタ
L401 WH145900 COIL
100uH CDRH127/LDNP-101MC
コイル１００Ｕ
03
L431 WH145900 COIL
100uH CDRH127/LDNP-101MC
コイル１００Ｕ
03
L451 WH145900 COIL
100uH CDRH127/LDNP-101MC
コイル１００Ｕ
03
L481 WH145900 COIL 100uH CDRH127/LDNP-101MC
コイル１００Ｕ
03
*
L551 ZJ245600 COIL INDUCTOR (CHIP) 470uH CER1065B-471M
チップインダクタ
L601 WH743700 INDUCTANCE (CHIP) 100uH 7E10N-101M-R
チップインダクタ
02
L631 WH743700 INDUCTANCE (CHIP) 100uH 7E10N-101M-R
チップインダクタ
02
L701 WZ873300 INDUCTANCE (CHIP) CER7052-220M-R
チップインダクタ
01
L731 WF468000 INDUCTANCE (CHIP) 22uH 7E10H-220
チップインダクタ
02
LD001 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
OVER CURRENT PROTECTION 01
LD002 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
01
R001 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R002 RD356100 CARBON RESISTOR (CHIP) 1.0K 63M J RECT.
チップ抵抗
01
R003 RD356470 CARBON RESISTOR (CHIP) 4.7K 63M J RECT.
チップ抵抗
R004 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R005 RD357100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R006 WZ388000 CARBON RESISTOR (CHIP) 0.33 1W J 5025
チップ抵抗
01
-011 WZ388000 CARBON RESISTOR (CHIP) 0.33 1W J 5025
チップ抵抗
01
R012 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R013 RD356470 CARBON RESISTOR (CHIP) 4.7K 63M J RECT.
チップ抵抗
R014 RD357150 CARBON RESISTOR (CHIP) 15.0K 63M J RECT.
チップ抵抗
R015 RD356100 CARBON RESISTOR (CHIP) 1.0K 63M J RECT.
チップ抵抗
01
R016 RD358220 CARBON RESISTOR (CHIP) 220.0K 63M J RECT.
チップ抵抗
R017 RD358331 CARBON RESISTOR (CHIP) 330.0K 63M J RECT.
チップ抵抗
01
R018 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R019 RF457100 CARBON RESISTOR (CHIP) 10.0K D RECT.
チップ抵抗
R020 RF456270 CARBON RESISTOR (CHIP) 2.7K D RECT.
チップ抵抗
R021 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R022 RD356100 CARBON RESISTOR (CHIP) 1.0K 63M J RECT.
チップ抵抗
01
R041
WW770000 CARBON RESISTOR (CHIP) 2.2K 1W J 5025
チップ抵抗
01
R042 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R043 RF456150 CARBON RESISTOR (CHIP) 1.5K D RECT.
チップ抵抗
R044 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R045 RD357470 CARBON RESISTOR (CHIP) 47.0K 63M J RECT.
チップ抵抗
R046 RD355470 CARBON RESISTOR (CHIP) 470.0 63M J RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
DCM

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
