Yamaha QL5 Service Manual

51
QL5/QL1
R047 RD355820 CARBON RESISTOR (CHIP) 820.0 63M J RECT.
チップ抵抗
R048 RD355470 CARBON RESISTOR (CHIP) 470.0 63M J RECT.
チップ抵抗
R049 RD355820 CARBON RESISTOR (CHIP) 820.0 63M J RECT.
チップ抵抗
-056 RD355820 CARBON RESISTOR (CHIP) 820.0 63M J RECT.
チップ抵抗
R101 RF457180 CARBON RESISTOR (CHIP) 18.0K D RECT.
チップ抵抗
R102 RD35410R CARBON RESISTOR (CHIP) 10.0 63M J RECT.
チップ抵抗
01
R103 RD35410R CARBON RESISTOR (CHIP) 10.0 63M J RECT.
チップ抵抗
01
R104 RD350000 CARBON RESISTOR (CHIP) 0 63M J RECT.
チップ抵抗
R106 RD356220 CARBON RESISTOR (CHIP) 2.2K 63M J RECT.
チップ抵抗
01
R107 RD358100 CARBON RESISTOR (CHIP) 100.0K 63M J RECT.
チップ抵抗
01
R109 RD357750 CARBON RESISTOR (CHIP) 75.0K 63M J RECT.
チップ抵抗
R110 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R111 RF457470 CARBON RESISTOR (CHIP) 47.0K D RECT.
チップ抵抗
01
R112 RF457330 CARBON RESISTOR (CHIP) 33.0K D RECT.
チップ抵抗
R114 RD357100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R131 RD358100 CARBON RESISTOR (CHIP) 100.0K 63M J RECT.
チップ抵抗
01
R133 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R134 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R135 RD357150 CARBON RESISTOR (CHIP) 15.0K 63M J RECT.
チップ抵抗
R136 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R137 RF457100 CARBON RESISTOR (CHIP) 10.0K D RECT.
チップ抵抗
R138 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R153 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R154 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R155 RD357150 CARBON RESISTOR (CHIP) 15.0K 63M J RECT.
チップ抵抗
R156 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R157 RF457100 CARBON RESISTOR (CHIP) 10.0K D RECT.
チップ抵抗
R158 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R183 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R184 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R185 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R186 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R187 RF457180 CARBON RESISTOR (CHIP) 18.0K D RECT.
チップ抵抗
R188 RF456680 CARBON RESISTOR (CHIP) 6.8K D RECT.
チップ抵抗
R231 RD156100 CARBON RESISTOR (CHIP) 1.0K 1/4 J TP
チップ抵抗
R232 RD355100 CARBON RESISTOR (CHIP) 100.0 63M J RECT.
チップ抵抗
R251 RD356470 CARBON RESISTOR (CHIP) 4.7K 63M J RECT.
チップ抵抗
R252 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R253 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R254 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R255 RF456220 CARBON RESISTOR (CHIP) 2.2K D RECT.
チップ抵抗
R256 RF456220 CARBON RESISTOR (CHIP) 2.2K D RECT.
チップ抵抗
R257 RD356680 CARBON RESISTOR (CHIP) 6.8K 63M J RECT.
チップ抵抗
R258 RD357680 CARBON RESISTOR (CHIP) 68.0K 63M J RECT.
チップ抵抗
R259 RD358100 CARBON RESISTOR (CHIP) 100.0K 63M J RECT.
チップ抵抗
01
R260 RD356820 CARBON RESISTOR (CHIP) 8.2K 63M J RECT.
チップ抵抗
R261 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R262 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R263 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R264 RF456220 CARBON RESISTOR (CHIP) 2.2K D RECT.
チップ抵抗
R265 RF457270 CARBON RESISTOR (CHIP) 27.0K D RECT.
チップ抵抗
R266 RD358180 CARBON RESISTOR (CHIP) 180.0K 63M J RECT.
チップ抵抗
01
R267 RD356220 CARBON RESISTOR (CHIP) 2.2K 63M J RECT.
チップ抵抗
01
R281 RD358100 CARBON RESISTOR (CHIP) 100.0K 63M J RECT.
チップ抵抗
01
R283 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R284 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R285 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R286 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R287 RF457180 CARBON RESISTOR (CHIP) 18.0K D RECT.
チップ抵抗
R288 RF456680 CARBON RESISTOR (CHIP) 6.8K D RECT.
チップ抵抗
R289 RD35527R CARBON RESISTOR (CHIP) 270.0 63M J RECT.
チップ抵抗
01
R301 RD356390 CARBON RESISTOR (CHIP) 3.9K 63M J RECT.
チップ抵抗
R302 RD358470 CARBON RESISTOR (CHIP) 470.0K 63M J RECT.
チップ抵抗
R303 RD357220 CARBON RESISTOR (CHIP) 22.0K 63M J RECT.
チップ抵抗
R304 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
R305 RF457180 CARBON RESISTOR (CHIP) 18.0K D RECT.
チップ抵抗
R306 RF456680 CARBON RESISTOR (CHIP) 6.8K D RECT.
チップ抵抗
R401 RD15656R CARBON RESISTOR (CHIP) 5.6K 1/4 J TP
チップ抵抗
01
R402 RD15656R CARBON RESISTOR (CHIP) 5.6K 1/4 J TP
チップ抵抗
01
R403 RF456470 CARBON RESISTOR (CHIP) 4.7K D RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
