Yamaha QL5 Service Manual

96
QL5/QL1
LD212 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 18 OVER 01
QL1: CHANNEL 2 OVER
LD213 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 18 -6
QL1: CHANNEL 2 -6
LD214 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 18 -12
QL1: CHANNEL 2 -12
LD215 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 18 -18
QL1: CHANNEL 2 -18
LD216 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 18 -30 01
QL1: CHANNEL 2 -30
LD217 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 18 -60 01
QL1: CHANNEL 2 -60
LD218 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 18 ON 01
QL1: CHANNEL 2 ON
*
LD219 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 19 SEL
QL1: CHANNEL 3 SEL
LD220 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 19 CUE 01
QL1: CHANNEL 3 CUE
LD221 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 19 OVER 01
QL1: CHANNEL 3 OVER
LD222 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 19 -6
QL1: CHANNEL 3 -6
LD223 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 19 -12
QL1: CHANNEL 3 -12
LD224 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 19 -18
QL1: CHANNEL 3 -18
LD225 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 19 -30 01
QL1: CHANNEL 3 -30
LD226 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 19 -60 01
QL1: CHANNEL 3 -60
LD227 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 19 ON 01
QL1: CHANNEL 3 ON
*
LD228 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 20 SEL
QL1: CHANNEL 4 SEL
LD229 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 20 CUE 01
QL1: CHANNEL 4 CUE
LD230 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 20 OVER 01
QL1: CHANNEL 4 OVER
LD231 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 20 -6
QL1: CHANNEL 4 -6
LD232 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 20 -12
QL1: CHANNEL 4 -12
LD233 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 20 -18
QL1: CHANNEL 4 -18
LD234 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 20 -30 01
QL1: CHANNEL 4 -30
LD235 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 20 -60 01
QL1: CHANNEL 4 -60
LD236 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 20 ON 01
QL1: CHANNEL 4 ON
*
LD237 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 21 SEL
QL1: CHANNEL 5 SEL
LD238 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 21 CUE 01
QL1: CHANNEL 5 CUE
LD239 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 21 OVER 01
QL1: CHANNEL 5 OVER
LD240 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 21 -6
QL1: CHANNEL 5 -6
LD241 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 21 -12
QL1: CHANNEL 5 -12
LD242 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 21 -18
QL1: CHANNEL 5 -18
LD243 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 21 -30 01
QL1: CHANNEL 5 -30
LD244
WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 21 -60 01
QL1: CHANNEL 5 -60
LD245 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 21 ON 01
QL1: CHANNEL 5 ON
*
LD246 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 22 SEL
QL1: CHANNEL 6 SEL
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
PN16M

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
