Yamaha QL5 Service Manual

97
QL5/QL1
LD247 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 22 CUE 01
QL1: CHANNEL 6 CUE
LD248 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 22 OVER 01
QL1: CHANNEL 6 OVER
LD249 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 22 -6
QL1: CHANNEL 6 -6
LD250 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 22 -12
QL1: CHANNEL 6 -12
LD251 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 22 -18
QL1: CHANNEL 6 -18
LD252 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 22 -30 01
QL1: CHANNEL 6 -30
LD253 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 22 -60 01
QL1: CHANNEL 6 -60
LD254 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 22 ON 01
QL1: CHANNEL 6 ON
*
LD255 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 23 SEL
QL1: CHANNEL 7 SEL
LD256 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 23 CUE 01
QL1: CHANNEL 7 CUE
LD257 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 23 OVER 01
QL1: CHANNEL 7 OVER
LD258 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 23 -6
QL1: CHANNEL 7 -6
LD259 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 23 -12
QL1: CHANNEL 7 -12
LD260 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 23 -18
QL1: CHANNEL 7 -18
LD261 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 23 -30 01
QL1: CHANNEL 7 -30
LD262 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 23 -60 01
QL1: CHANNEL 7 -60
LD263
ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 23 ON 01
QL1: CHANNEL 7 ON
*
LD264 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 24 SEL
QL1: CHANNEL 8 SEL
LD265 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 24 CUE 01
QL1: CHANNEL 8 CUE
LD266 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 24 OVER 01
QL1: CHANNEL 8 OVER
LD267 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 24 -6
QL1: CHANNEL 8 -6
LD268 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 24 -12
QL1: CHANNEL 8 -12
LD269 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 24 -18
QL1: CHANNEL 8 -18
LD270 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 24 -30 01
QL1: CHANNEL 8 -30
LD271 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 24 -60 01
QL1: CHANNEL 8 -60
LD272 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 24 ON 01
QL1: CHANNEL 8 ON
*
LD401 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: CHANNEL 25 SEL
QL1: CHANNEL 9 SEL
LD402 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 25 CUE 01
QL1: CHANNEL 9 CUE
LD403 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
QL5: CHANNEL 25 OVER 01
QL1: CHANNEL 9 OVER
LD404 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 25 -6
QL1: CHANNEL 9 -6
LD405 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 25 -12
QL1: CHANNEL 9 -12
LD406 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
QL5: CHANNEL 25 -18
QL1: CHANNEL 9 -18
LD407 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 25 -30 01
QL1: CHANNEL 9 -30
LD408 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
QL5: CHANNEL 25 -60 01
QL1: CHANNEL 9 -60
LD409 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
QL5: CHANNEL 25 ON 01
QL1: CHANNEL 9 ON
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
PN16M

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
