Yamaha QL5 Service Manual

103
QL5/QL1
CN506 V9560600 FFC/FPC CONNECTOR 52808 22P TE
ＦＦＣ／ＦＰＣコネクター
02
CN601 WC19500R FFC/FPC CONNECTOR 52808 12P TE
ＦＦＣ／ＦＰＣコネクター
01
-608 WC19500R FFC/FPC CONNECTOR 52808 12P TE
ＦＦＣ／ＦＰＣコネクター
01
D101 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
D102 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
D201 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
-224 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
D301 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
D302 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
D401 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
-424 WG139300 DIODE (CHIP) KDS4148U-RTK/P TE
チップダイオード
EM101 ZC805200 EMI FILTER (CHIP) 31PT222Z1E9L TP
チップエミフィル
01
EM102 ZC805200 EMI FILTER (CHIP) 31PT222Z1E9L TP
チップエミフィル
01
FT101 ZA683700 FET (CHIP) US6K1TR
チップＦＥＴ
01
-104 ZA683700 FET (CHIP) US6K1TR
チップＦＥＴ
01
FT301 ZA683700 FET (CHIP) US6K1TR
チップＦＥＴ
01
-304 ZA683700 FET (CHIP) US6K1TR
チップＦＥＴ
01
IC101 YE031100 IC M38039G4H-819HP
ＩＣ
CPU (EC-PNS1)
IC102 X5965A0R IC SN74LV04APWR
ＩＣ
INVERTER 01
IC103 X5965A0R IC SN74LV04APWR
ＩＣ
INVERTER 01
IC301 YE031100 IC M38039G4H-819HP
ＩＣ
CPU (EC-PNS1)
IC302 X5965A0R IC SN74LV04APWR
ＩＣ
INVERTER 01
IC303 X5965A0R IC SN74LV04APWR
ＩＣ
INVERTER 01
IC506 X7618A00 IC SN74LV139APWR
ＩＣ
DECODER 02
IC507 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC508 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC601 YD685A00 IC TLC5941PWPR
ＩＣ
LED DRIVER 04
-604 YD685A00 IC TLC5941PWPR
ＩＣ
LED DRIVER 04
*
LD201 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 1 SEL
LD202 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 1 CUE 01
LD203 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 1 OVER 01
LD204 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 1 -6
LD205 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 1 -12
LD206 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 1 -18
LD207 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 1 -30 01
LD208 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 1 -60 01
LD209 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 1 ON 01
*
LD210 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 2 SEL
LD211 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 2 CUE 01
LD212 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 2 OVER 01
LD213 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 2 -6
LD214 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 2 -12
LD215 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 2 -18
LD216 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 2 -30 01
LD217 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 2 -60 01
LD218 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 2 ON 01
*
LD219 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 3 SEL
LD220 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 3 CUE 01
LD221 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 3 OVER 01
LD222 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 3 -6
LD223 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 3 -12
LD224 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 3 -18
LD225 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 3 -30 01
LD226 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 3 -60 01
LD227 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 3 ON 01
*
LD228 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 4 SEL
LD229 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 4 CUE 01
LD230 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 4 OVER 01
LD231 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 4 -6
LD232 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 4 -12
LD233 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 4 -18
LD234 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 4 -30 01
LD235 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 4 -60 01
LD236 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 4 ON 01
*
LD237 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 5 SEL
LD238 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 5 CUE 01
LD239 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 5 OVER 01
LD240 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 5 -6
LD241 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 5 -12
LD242 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 5 -18
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
PN16S(QL5)
