Yamaha QL5 Service Manual

104
QL5/QL1
LD243 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 5 -30 01
LD244 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 5 -60 01
LD245 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 5 ON 01
*
LD246 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 6 SEL
LD247 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 6 CUE 01
LD248 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 6 OVER 01
LD249 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 6 -6
LD250 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 6 -12
LD251 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 6 -18
LD252 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 6 -30 01
LD253 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 6 -60 01
LD254 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 6 ON 01
*
LD255 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 7 SEL
LD256 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 7 CUE 01
LD257 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 7 OVER 01
LD258 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 7 -6
LD259 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 7 -12
LD260 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 7 -18
LD261 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 7 -30 01
LD262 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 7 -60 01
LD263 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 7 ON 01
*
LD264 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 8 SEL
LD265 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 8 CUE 01
LD266 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 8 OVER 01
LD267 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 8 -6
LD268 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 8 -12
LD269 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 8 -18
LD270 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 8 -30 01
LD271 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 8 -60 01
LD272 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 8 ON 01
*
LD401 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 9 SEL
LD402 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 9 CUE 01
LD403 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 9 OVER 01
LD404 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 9 -6
LD405 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 9 -12
LD406 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 9 -18
LD407 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 9 -30 01
LD408 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 9 -60 01
LD409 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 9 ON 01
*
LD410 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 10 SEL
LD411 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 10 CUE 01
LD412 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 10 OVER 01
LD413 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 10 -6
LD414 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 10 -12
LD415 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 10 -18
LD416 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 10 -30 01
LD417 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 10 -60 01
LD418 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 10 ON 01
*
LD419 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 11 SEL
LD420 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 11 CUE 01
LD421 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 11 OVER 01
LD422 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 11 -6
LD423 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 11 -12
LD424 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 11 -18
LD425 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 11 -30 01
LD426 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 11 -60 01
LD427 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 11 ON 01
*
LD428 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 12 SEL
LD429 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 12 CUE 01
LD430 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 12 OVER 01
LD431 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 12 -6
LD432 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 12 -12
LD433 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 12 -18
LD434 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 12 -30 01
LD435 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 12 -60 01
LD436 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 12 ON 01
*
LD437 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 13 SEL
LD438 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 13 CUE 01
LD439 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 13 OVER 01
LD440 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 13 -6
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
PN16S(QL5)
