Yamaha QL5 Service Manual

105
QL5/QL1
LD441 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 13 -12
LD442 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 13 -18
LD443 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 13 -30 01
LD444 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 13 -60 01
LD445 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 13 ON 01
*
LD446 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 14 SEL
LD447 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 14 CUE 01
LD448 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 14 OVER 01
LD449 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 14 -6
LD450 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 14 -12
LD451 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 14 -18
LD452 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 14 -30 01
LD453 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 14 -60 01
LD454 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 14 ON 01
*
LD455 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 15 SEL
LD456 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 15 CUE 01
LD457 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 15 OVER 01
LD458 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 15 -6
LD459 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 15 -12
LD460 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 15 -18
LD461 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 15 -30 01
LD462 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 15 -60 01
LD463 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 15 ON 01
*
LD464 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
CHANNEL 16 SEL
LD465 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 16 CUE 01
LD466 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
CHANNEL 16 OVER 01
LD467 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 16 -6
LD468 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 16 -12
LD469 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
CHANNEL 16 -18
LD470 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 16 -30 01
LD471 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
CHANNEL 16 -60 01
LD472 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
CHANNEL 16 ON 01
LD601 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 1 03
LD602 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 2 03
LD603 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 3 03
LD604 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 4 03
LD605 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 5 03
LD606 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 6 03
LD607 ZD114500
LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 7 03
LD608 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 8 03
LD609 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 9 03
LD610 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 10 03
LD611 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 11 03
LD612 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 12 03
LD613 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 13 03
LD614 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 14 03
LD615 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 15 03
LD616 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
CHANNEL 16 03
R101 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
-103 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
R104 RD357100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R105 RD350000 CARBON RESISTOR (CHIP) 0 63M J RECT.
チップ抵抗
R106 RD356100 CARBON RESISTOR (CHIP) 1.0K 63M J RECT.
チップ抵抗
01
R107 RD354270 CARBON RESISTOR (CHIP) 27.0 63M J RECT.
チップ抵抗
R108 RD354560 CARBON RESISTOR (CHIP) 56.0 63M J RECT.
チップ抵抗
R109 RD355180 CARBON RESISTOR (CHIP) 180.0 63M J RECT.
チップ抵抗
R110 RD35527R CARBON RESISTOR (CHIP) 270.0 63M J RECT.
チップ抵抗
01
-112 RD35527R CARBON RESISTOR (CHIP) 270.0 63M J RECT.
チップ抵抗
01
R113 RD354560 CARBON RESISTOR (CHIP) 56.0 63M J RECT.
チップ抵抗
-115 RD354560 CARBON RESISTOR (CHIP) 56.0 63M J RECT.
チップ抵抗
R120 RD357100
CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
-127 RD357100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R129 RD350000 CARBON RESISTOR (CHIP) 0 63M J RECT.
チップ抵抗
R301 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
-303 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
R304 RD357100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R305 RD350000 CARBON RESISTOR (CHIP) 0 63M J RECT.
チップ抵抗
R306 RD356100 CARBON RESISTOR (CHIP) 1.0K 63M J RECT.
チップ抵抗
01
R307 RD354270 CARBON RESISTOR (CHIP) 27.0 63M J RECT.
チップ抵抗
R308 RD354560 CARBON RESISTOR (CHIP) 56.0 63M J RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
PN16S(QL5)
