QL5/QL1
BLOCK DIAGRAM 005 (QL5/QL1)
BLOCK DIAGRAM 005 (QL5/QL1)
28CA1-2001135745-5
DNT, Brooklyn2
Gigabit Ethernet
Switching HUB IC
P0 P1
P5
LED Driver
P2
P3P4
OSC
25MHz
Control
RGMII
PHY
Control
Audio
Data, Clock
Ethernet for PC
Dante
SECONDARY
Dante
PRIMARY
LINK
/ACT
1G
SECONDARY
LINK
/ACT
1G
PRIMARY
Link Status LEDs
1000BASE-T
100BASE-TX
Ethernet
(Editor)
UART
SPI
MUTE
Status
1.8V
1.0V3.3V
3.3V
1.8V
Ethernet
(SCP/
Nuendo Extension)
Brooklyn2
(Dante Module)
QL1: 32in 32out
QL5: 64in 64out
2 MAC Address inside
RGMII
MDIO
/RESET
QL5
DNT5
QL1
DNT1
QL5
DSP32
QL1
DSP16
CPUQL
CN221(38P),
CN222(38P)
CN101(180P)
CN601(180P)
CN101(126P)
X101
IC101
JK101
JK102
LD101-104
JK103
CN221(38P),
CN222(38P)
