Yanmar 3JH5E - 4 JH5 E Marine Gear or Sail Drive

SPECIFICATIONS
102 JH Series Operation Manual
4JH5E Marine Gear or Sail Drive
Model KM35P ZF30M
Type Mechanical cone clutch Mechanical wet maliple disk clutch
Reduction Ratio (forward / reverse) 2.36 / 3.16
2.61 / 3.16
2.15 / 2.64
2.70 / 2.64
Propeller Speed (forward / reverse)
(min
-1
)
*
1232 / 921
1114 / 921
1353 / 1103
1078 / 1103
Lubrication System Splash
Lubricating Oil Capacity (total) 0.5 L (0.5 qt) 1.1 L (1.2 qt)
**
Lubricating Oil Capacity (effective) 0.05 L (0.05 qt) 0.2 L (0.2 qt)
Cooling System Air cooling by fan Seawater cooling
Weight 12 kg (26 lb) 27.5 kg (61 lb)
* At continuous power engine speed 2907 min
-1
** ZF30M Lubricating oil: ATF
Model KM35A2 KM4A1
SD60-5
(coupled at boat builder)
Type Mechanical cone clutch Mechanical multiple friction
disc clutch
Reduction Ratio
(forward / reverse)
2.33 / 3.06
2.64 / 3.06
1.47 / 1.47
2.14 / 2.14
2.63 / 2.63
2.23 / 2.23
2.49 / 2.49
Propeller Speed
(forward / reverse) (min
-1
)
*
1246 / 950
1103 / 950
1983 / 1983
1360 / 1360
1106 / 1106
1304 / 1304
1167 / 1167
Lubrication System Splash Centrifugal pump Oil bath
Lubricating Oil Capacity (total) 0.65 L (0.69 qt) 2.3 L (2.4 qt) 2.8 L (3.0 qt)
Long Reach
(75mm): 3.0 L (3.2 qt)
Lubricating Oil Capacity (effective) 0.15 L (0.16 qt) 0.20 L (0.21 qt) -
Cooling System Air cooling by fan Seawater cooling -
Weight 13 kg (28 lb) 29 kg (64 lb)
43.6 kg (96.1 lb)
Long Reach (75mm):
48.2 kg (106.2 lb)
* At continuous power engine speed 2907 min
-1
