Yanmar 3JH5E User Manual

JH Series Operation Manual 143
EPA WARRANTY USA
ONLY
YANMAR CO., LTD. LIMITED EMISSION CONTROL SYSTEM
WARRANTY - USA ONLY
3JH5E EPA and ARB Nameplate
Figure 1
4JH5E EPA Nameplate
Figure 2
4JH4-TE EPA Nameplate
Figure 3
Figure 1 4JH4-HTE1 EPA Nameplate
Figure 4
YANMAR CO., LTD.
129271-07712
STANDARDS NOx+HC: 7.5g/kW-hr CO: 5.5g/kW-hr PM: 0.30g/kW-hr
EMISSION CONTROL INFORMATION
THIS ENGINE COMPLIES WITH U.S. EPA MARINE AND CALIFORNIA OFF-ROAD
REGULATIONS FOR 2013 M.Y. DIESEL ENGINES.
ULTRA LOW SULFUR DIESEL FUEL ONLY.
ENGINE FAMILY: DYDXN1.64D3N
ENGINE MODEL: 3JH5E E. C. S. : EM DFI
FUEL RATE: 32.5MM
3
6752.(#N:530N:
APPLICATION: VARIABLE-SPEED PROPULSION ENGINES USED WITH
FIXED- PITCH PROPEL L ERS.
DISPLACEMENT: 1.642 LITERS
YANMAR CO., LTD.
STANDARDS NOx+HC : 7.5g/kW-hr CO : 5.0g/kW-hr PM : 0.30g/kW-hr
EMISSION CONTROL INFORMATION
THIS MARINE ENGINE COMPLIES WITH U.S. EPA REGULATIONS FOR
2013.ULTRA LOW SULFUR DIESEL FUEL ONLY.
ENGINE FAMILY : DYDXN2.19D4N ENGINE MODEL : 4JH5E
APPLICATION : VARIABLE-SPEED PROPULSION ENGINES USED
EMISSION CONTROL SYSTEM : EM
REFER TO OWNER’S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.
W ITH FIXED - PITC H PR OPEL L ER S.
129670-07711
YANMAR CO., LTD.
STANDARDS NOx+HC : 7.5g/kW-hr CO : 5.0g/kW-hr PM : 0.30g/kW-hr
EMISSION CONTROL INFORMATION
THIS MARINE ENGINE COMPLIES WITH U.S. EPA REGULATIONS FOR
2013.ULTRA LOW SULFUR DIESEL FUEL ONLY.
ENGINE FAMILY : DYDXN2.00D4T ENGINE MODEL : 4JH4-TE
APPLICATION : VARIABLE-SPEED PROPULSION ENGINES USED
EMISSION CONTROL SYSTEM : EM
REFER TO OWNER’S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.
W ITH FIXED - PITC H PR OPEL L ER S.
129671-07711
YANMAR CO., LTD.
STANDARDS NOx+HC : 7.5g/kW-hr CO : 5.0g/kW-hr PM : 0.30g/kW-hr
EMISSION CONTROL INFORMATION
THIS MARINE ENGINE COMPLIES WITH U.S. EPA REGULATIONS FOR
2013.ULTRA LOW SULFUR DIESEL FUEL ONLY.
ENGINE FAMILY : DYDXN2.00D4H ENGINE MODEL : 4JH4-HTE1
APPLICATION : VARIABLE-SPEED PROPULSION ENGINES USED
EMISSION CONTROL SYSTEM : EM
REFER TO OWNER’S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.
W ITH FIXED - PITC H PR OPEL L ER S.
129672-07711
JH5_EN_OPM.book 143 ページ ２０１３年８月８日 木曜日 午前９時２３分

Yanmar 3JH5E Specifications

General

Number of Cylinders	3
Displacement	1.642 L
Combustion System	Direct injection
Aspiration	Naturally aspirated
Alternator	12V - 80A
Cooling System	Freshwater cooling
Starting System	Electric starting
Engine Type	Vertical, water-cooled 4-cycle diesel engine
Compression Ratio	23:1
