SPECIFICATIONS
104 JH Series Operation Manual
4JH4-HTE1 Engine
Note: Density of fuel: 0.842g/cm
3
at 15°C. Fuel temperature at the inlet of the fuel injection pump.
Note: 1 hp metric = 0.7355 kW
Engine Model 4JH4-HTE1
Marine Gear Model ZF30M KM4A2 KMH4A ZF25A Bobtail
Use Pleasure use
Type Vertical water cooled 4-cycle diesel engine
Combustion System Direct injection
Air Charging Turbocharged
Number of Cylinders 4
Bore x Stroke 84 x 90 mm (3.31 x 3.54 in.)
Displacement 1.995 L (121.74 cu in.)
Continuous power 65.1 kW (88.5 hp metric) / 3101 min
-1
*
Fuel stop
power
Output at crankshaft /
engine speed
71.6 kW (97.3 hp metric) / 3200 min
-1
*
Output at propeller /
engine speed
68.7 kW (93.4 hp metric) / 3200 min
-1
*-
Installation Flexible mounting
Fuel Injection Timing Plunger lift at TDC 1.26 ± 0.1 mm (when W-CSD is released)
Fuel Injection Opening Pressure 21.6 ± 0.5 MPa
Main Power Take Off At flywheel end
Direction of
Rotation
Crankshaft Counterclockwise viewed from stern
Propeller shaft
(Ahead)
Clockwise
from stern
Clockwise or counterclockwise
(Bi-rotation)
-
Cooling System Coolant cooling with heat exchanger
Lubrication System Forced lubrication system
Cooling Water Capacity (fresh) Engine: 7.2 L (7.6 qt), Reservoir: 0.8 L (0.8 qt)
Lubricating
Oil Capacity
(engine)
Rake angle 7° 0° 7° or 0°
Total
**
5.7 ± 0.3 L
(6.0 ± 0.3 qt)
6.9 ± 0.3 L
(7.3 ± 0.3 qt)
Refer to left
Oil pan only 5.2 ± 0.3 L
(5.5 ± 0.3 qt)
6.4 ± 0.3 L
(6.8 ± 0.3 qt)
Refer to left
Effective
***
2.4 L (2.5 qt)
Starting
System
Type Electric
Starting motor DC 12 V - 1.4 kW
AC generator 12 V - 120 A
Engine
Dimension
Overall length
923 mm (36.3 in.) 903 mm (35.6 in.) 933 mm (36.7 in.)
1017 mm 40.0 in.)
782 mm (30.8 in.)
Overall width 616 mm (24.3 in.)
Overall height 659 mm (25.9 in.)
Flywheel Major Dimension D339 x 66 mm (13.3 x 2.6 in.)
Engine Dry Mass (including marine gear)
245 kg (540 lb) 247 kg (545 lb) 248 kg (547 lb) 247 kg (545 lb) 217 kg (478 lb)
* Rating Condition: Temperature of fuel; 40°C at fuel pump inlet; ISO 8665
** The “total” oil quantity includes oil in oil pan, channels, coolers and filter.
*** The effective amount of oil shows the difference in maximum scale of the dipstick and minimum scale.
