BEFORE YOU OPERATE
JH Series Operation Manual 41
12/05
2. Fill with oil to the upper limit
(Figure 8, (4)) on the dipstick
(Figure 8, (3)).
NOTICE
Never overfill the engine with engine oil.
3. Insert the dipstick fully to check the
level.
NOTICE
Always keep the oil level between upper
and lower lines on the oil cap / dipstick.
4. Hand-tighten the filler port cap
securely.
MARINE GEAR OR SAIL
DRIVE OIL
Marine Gear Oil Specifications
Use marine gear oil that meets or exceeds
the following guidelines and classifications:
KM35P, KM35A, KM35A2, KM4A1,
KM4A2, KMH4A:
• API Service Categories CD or higher
• SAE Viscosity #20 or #30
ZF30M, ZF25A:
• ATF (Automatic Transmission Fluid)
Sail Drive Oil Specifications
Refer to the Operation Manual of the sail
drive for the procedure to fill or replace the
sail drive oil.
3JH5E, 4JH5E (SD60-5)
4JH4-TE (SD60-4):
• API Service Categories CD or higher
• SAE Viscosity 15W-40
