Yanmar 3JH5E - System Diagrams; Piping Diagrams

JH Series Operation Manual 107
SYSTEM DIAGRAMS
PIPING DIAGRAMS
Note:
• Dimension of steel pipe: outer diameter x thickness.
• Dimension of rubber pipe: inner diameter x thickness.
• Fuel rubber pipes (marked *) satisfy EN / ISO7840.
Notation Description
Screw Joint (Union)
Flange Joint
Eye Joint
Insertion Joint
Drilled Hole
Coolant Piping
Cooling Seawater Piping
Lubricating Oil Piping
Diesel Fuel Piping
