PRODUCT OVERVIEW
24 JH Series Operation Manual
Meters
Note: The LCD on the instrument panel show hourmeter, display brightness and
battery voltage.
Coolant temperature and oil pressure display (option)
･B20-Type panels have a digital LCD screen inside the tachometer.
･C30-Type panels have an electric gauge with a needle.
Instrument Function
Tachometer Shows engine rotation speed.
Hourmeter Shows number of operating hours. Can be used as a guide for periodic
maintenance checks. The hourmeter is located at the bottom of the
tachometer.
Coolant Temperature Gauge Shows the coolant temperature.
Engine Oil Pressure Gauge Shows the engine oil pressure.
Panel Lights When the power switch is pushed, the gauges will illuminate for easier viewing.
