31 support@yardistrystructures.com
F: In the grooves of each (1113) Back Post slide one (1155) Vent Wall Panel down so it rests tight to the top of
the (1120) Back Base. Vent should be closer to the (1120) Back Base. (F3.8 and F3.9)
Step 3: Back Wall Assembly
Part 4
Wood Parts
1 x (1155) Vent Wall Panel
F3.8
(1113)
Back Post
F3.9
(1155) Vent
Wall Panel
(1113)
Back Post
(1120) Back
Base
(1155) Vent
Wall Panel
(1120) Back
Base
Notice vent is
towards the
bottom of the
panel
