35 support@yardistrystructures.com
#10 X 4” Wood Screws
CONNECT THE GABLE BACK BEAM
TO THE BACK POSTS .
Step 3: Back Wall Assembly
Part 8
L:
attach with two #10 x 4” Wood Screws per post. (F3.17 and F3.18)
Hardware
4 x #10 x 4” Wood Screw
#10 x 4”
Wood Screw
(1113)
Back
Post
#10 X 4” Wood Screws
CONNECT THE GABLE BACK BEAM
TO THE BACK POSTS .
#10 x 4”
Wood Screw
(1113) Back Post
(1117) Back
Gable Beam
(1117) Back
Gable Beam
F3.17
F3.18
