5 Installation Procedure
18 YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual
 Option Baud Rate
The option supports standard baud rates of 125 kbps, 250 kbps, and 500 kbps.
Table 5 Parameter F6-51 Baud Rate Setting
 Auto Baud Rate Sensing (F6-51 = 4)
Setting parameter F6-51 to 4 enables automatic baud rate detection and allows the option to automatically determine the
baud rate of the DeviceNet network.
Note: Auto baud rate sensing is valid only when there is more than one node physically on the DeviceNet network segment. If the auto
baud rate sensing fails to detect the baud rate, the drive digital operator will display “bUS” and the option LEDs will be OFF
(NS) and solid green (MS).
 EDS Files
To facilitate network implementation, obtain an EDS file from one of the following websites depending on your region:
US: http://www.yaskawa.com
Europe: http://www.yaskawa.eu.com
Japan: http://www.e-mechatronics.com
Other areas: Contact your Yaskawa representative.
Description Value
125 kbps 0
250 kbps 1
500 kbps 2
Programmable from Network 3
Auto Detect 4
