YASKAWA 1000 Series

8 Output Assemblies (Drive Consumes)
28 YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual
 Enhanced Speed Control, Dynamic (Vendor Specific Yaskawa Electric (YE) Assy) -
105 (0x69)
Multi-Function Digital Output
Terminal M1/M2
0: M1/M2 OFF
1: M1/M2 ON
This function is enabled only when H2-01 is set to F.
Multi-Function Photocoupler 1
Terminal P1
0: P1 OFF
1: P1 ON
This function is enabled only when H2-02 is set to F.
Multi-Function Photocoupler 2
Terminal P2
0: P2 OFF
1: P2 ON
This function is enabled only when H2-03 is set to F.
Speed Reference
Speed Command
Sets drive speed reference
Unit depends on o1-03.
Unit is not affected by Speed Scale SS.
Acceleration Time 1
Acceleration Time 1 (C1-01)
Unit depends on C1-10.
Unit is not affected by Time Scale TS.
Deceleration Time 1
Deceleration Time 1 (C1-02)
Unit depends on C1-10.
Unit is not affected by Time Scale TS.
Output
Instance
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
105
0
Multi-
Function Input
8
Multi-
Function Input
7
Multi-
Function Input
6
Multi-
Function Input
5
Multi-
Function Input
4
Multi-
Function Input
3
Run
Rev
Run
Fwd
1
Multi-
Function
Photocoupler 2
Multi-
Function
Photocoupler 1
Multi-
Function
Digital Output
–
Function Code
High Bit
Function Code
Low Bit
Fault
Reset
External
Fault
2 Speed Reference (Low Byte)
3 Speed Reference (High Byte)
4 Register Number (Low Byte)
5 Register Number (High Byte)
6 Register Data (Low Byte)
7 Register Data (High Byte)
Name Description
Run Fwd
Forward Run Command
0: Stop
1: Forward Run
Run Rev
Reverse Run Command
0: Stop
1: Reverse Run
Multi-Function Input 3
Terminal S3 Function Input
0: Terminal S3 Function (H1-03) OFF
1: Terminal S3 Function (H1-03) ON
Multi-Function Input 4
Terminal S4 Function Input
0: Terminal S4 Function (H1-04) OFF
1: Terminal S4 Function (H1-04) ON
Multi-Function Input 5
Terminal S5 Function Input
0: Terminal S5 Function (H1-05) OFF
1: Terminal S5 Function (H1-05) ON
Multi-Function Input 6
Terminal S6 Function Input
0: Terminal S6 Function (H1-06) OFF
1: Terminal S6 Function (H1-06) ON
Parameter Data
