YASKAWA 1000 Series User Manual

9 Input Assemblies (Drive Produces)
52 YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual
REV Running
Reverse Running
0: Not Reverse Running
1: Reverse Running
Reset
Reset
0: No Reset
1: Reset
Speed Agree
Speed Agree
0: No Speed Agree
1: Actual speed at speed reference
READY
Drive Ready
0: Not Ready
1: Ready
ALARM
Drive Alarm
0: No Drive Alarm
1: Alarm
FAULT
Drive Fault
0: No Drive Fault
1: Fault
oPE
oPE Fault
0: No oPExx Fault
1: oPExx
Uv
Undervoltage
0: No Undervoltage
1: Undervoltage
LOCAL/REMOTE
Status of Run command from Network
0: Run command is not from network
1: Run command is from network
Multi-Function Digital Output
Terminal M1/M2
0: Terminal M1/M2 OFF
1: Terminal M1/M2 ON
Multi-Function Photocoupler 1
Terminal P1
0: Terminal P1 OFF
1: Terminal P1 ON
Multi-Function Photocoupler 2
Terminal P2
0: Terminal P2 OFF
1: Terminal P2 ON
Output Frequency
Actual Drive Speed
Monitors drive output frequency
Unit depends on o1-03.
Unit is not affected by Speed Scale SS.
Frequency Reference
Frequency Reference
Monitors drive frequency reference
Unit depends on o1-03.
Unit is not affected by Speed Scale SS.
Actual Current
Actual Output Current
Monitors drive output current
Unit is 0.1 A
Unit is not affected by Current Scale CS.
Parameter Data
