YASKAWA 1000 Series

12 Troubleshooting
76 YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual
 DeviceNet Option Fault Monitors U6-98 and U6-99
The DeviceNet Option SI-N3 can declare the error/warning conditions via drive monitor parameters as shown in
Table 22.
Table 22 DeviceNet Option Fault Monitor Descriptions
Two drive monitor parameters, U6-98 (OPTN LATCH STAT) and U6-99 (OPTN ACTIVE STAT), assist the user in
network troubleshooting.
• U6-98 displays the first declared fault since the last fault reset or power cycle.
• U6-99 displays the present DeviceNet Option SI-N3 status.
These parameters are accessible from the DeviceNet network the or the drive digital operator. A drive fault reset or
power off clears and refreshes both U6-98 and U6-99.
Note: In the event of a PLC idle state, the action taken by the DeviceNet Option SI-N3 depends upon the value of parameter F6-54
(Idle Mode Fault Detection).
 Automatic Device Replacement (ADR)
This DeviceNet Interface is compatible with the ADR feature associated with Rockwell controllers and DeviceNet
Scanners. ADR features Configuration Recovery and Auto Address Recovery.
 Configuration Recovery (CR)
CR is the ability of the scanner to download previously uploaded and saved configuration data to the DeviceNet node.
When a DeviceNet node is removed and returned to the network or replaced with another device, an ADR-enabled
scanner reads the Electronic Key of the device that is configured in the scanner. A typical setup of the Electronic Key is:
Vendor ID, Product Code, Model Number and Product Revision. When the CR feature is enabled, the stored
configuration is downloaded to the DeviceNet node.
1F 6320 EEPROM R/W Error (Err) Cycle drive power – Replace drive if fault continues
20 0000 None
21
7500 DeviceNet Comm Error (bUS)
Check DeviceNet network cable connections.
Check 24VDC power supply voltage.
22 Check DeviceNet Option Card installation and connections.
23
Cycle drive power – Replace DeviceNet Option or drive if fault continues.
24
25 8321 Out of Control (CF)
Check motor parameters
Auto-tune
27 9000 External Fault 0 (EF0)
Check PLC program
Check MI switch setting
Check DeviceNet Option Card LEDs for fault indication
<1> Drive error code is stored in MEMOBUS/Modbus address 0080 hex.
Fault Condition Fault Declared
Status Value (U6-99/
U6-98)
Description
No Fault n/a 0 No faults.
CPU Error EF0 1 Option board failure.
PLC in Idle State EF0 2 PLC is sending polled I/O with all data set to zero.
Force Fault EF0 3 Network sent a message to force this node to the fault state.
Network Power Loss BUS ERROR 1000 Power on DeviceNet network is off.
Connection Time-out BUS ERROR 1001 This nodes timer (Expect Packet Rate) timed out.
Dup MAC ID BUS ERROR 1002
This node and at least one other node have the same MAC ID.
Another node sent its MAC ID to the network first.
Bus-Off BUS ERROR 1003 CAN transceiver senses network error.
Drive Error
Code
(hex) <1>
DeviceNet
Error Code
(hex)
Description Corrective Action
