YASKAWA F7 Programming Manual

v
 480Vac
Table i.3 480Vac Drive Specifications
Model Number CIMR-F7U 40P4 40P7 41P5 42P2 43P7 44P0 45P5 47P5 4011 4015 4018 4022
Rated output capacity (kVA)
1.4 1.6 2.8 4.0 5.8 6.6 9.5 13.0 18.0 24.0 30.0 34.0
Horsepower
*2
0.5/0.75 1 1.5/2 3 5 - 7.5 10 15 20 25 30
Rated output current
(A)
1.8 2.1 3.7 5.3 7.6 8.7 12.5 17.0 24.0 31.0 39.0 45.0
Overload capacity
*3
(% of rated output
current for 60 sec.)
150
Current limit
*2
(% of
rated output current)
150
Carrier frequency
*4
2kHz
Maximum output
frequency
300.0Hz
Rated output capacity (kVA) 1.4 1.6 2.8 4.0 5.8 6.6 9.5 13.0 21.0 26.0 30.0 38.0
Horsepower
*2
0.5/0.75 1 1.5/2 3 5 - 7.5 10 15/20 25 30 30
Rated output current (A) 1.8 2.1 3.7 5.3 7.6 8.7 12.5 17.0 27.0 34.0 40.0 50.4
Overload capacity
*3
(% of rated output
current for 60 sec.)
120 120 120 120 120 120 120 120 107 109 117 107
Current limit (% of
rated output current)
120
Carrier frequency (kHz)
*5
15 15 15 15 15 15 15 15 8 10 10 10
Maximum output
frequency
400.0Hz
Maximum output voltage 3-phase; 380, 400, 415, 440, 460, or 480Vac (Proportional to input voltage)
Model Number CIMR-F7U 4030 4037 4045 4055
4075 4090 4110
4132 4160 4185 4220 4300
Rated output capacity (kVA)
46.0 57.0 69.0 85.0 110.0 140.0 160.0 200.0 230.0 280.0
N/A
Horsepower
*2
40 50 60 75 100 125/150 - 200 250 300
Rated output current
(A)
60.0 75.0 91.0 112.0 150.0 180.0 216.0 260.0 304.0 370.0
Overload capacity
*3
(% of rated output
current for 60 sec.)
150
Current Limit (% of
rated output current)
150
Carrier frequency
*4
2kHz
Maximum output
frequency
300.0Hz
Rated output capacity
(kVA)
51.0 59.0 73.0 95.0 120.0 140.0 180.0 200.0 230.0 315.0 390.0 510.0
Horsepower
*2
40/50 60 75 100 125 150 200 - 250 300/350 400/450 500+
Rated output current
(A)
67.2 77.0 96.0 125.0 156.0 180.0 240.0 260.0 304.0 414.0 515.0 675.0
Overload capacity
*3
(% of rated output
current for 60 sec.)
107 117 114 108 115 120 108 120 120 107 118 120
Current Limit (% of
rated output current)
120
Carrier frequency (kHz)
*5
8885585552 2 2
Maximum output
frequency
400.0Hz
Maximum output voltage 3-phase, 380, 400, 415, 440, 460 or 480Vac (Proportional to input voltage)
*1 The difference between Heavy Duty ratings and the Normal Duty ratings for the Drive are the rated input and output current, overload capacity, carrier frequency, current limit, and
maximum output frequency. Parameter C6-01 must be set to value of “0” for Heavy Duty ratings and “2” for Normal Duty ratings. Factory default is Heavy Duty (C6-01=0).
*2 Horsepower ratings are based on 230V or 460V NEC Table 430.150. The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor
and Drive, be sure that the Drive's rated output current is appropriate for the motor's rated current.
*3 Models 2110, 4220, 4300 have an overload rating of 120% of rated output current for 60 seconds.
*4 2kHz is the Maximum carrier frequency value and default carrier frequency value for all models.
*5 Each value shown is the Maximum carrier frequency and default carrier frequency.
O
utput rat
i
ngs
Heavy Duty
*1
Normal Duty
*1
O
utput rat
i
ngs
Heavy Duty
*1
Normal Duty
*
1

YASKAWA F7 Specifications

General

Series	F7
Type	DC Drive
Feedback	Tachometer, Encoder
Communication	RS-485, DeviceNet, Profibus, Modbus
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Storage Temperature	-20°C to +70°C (-4°F to 158°F)
Humidity	95% RH or less (non-condensing)
Enclosure Rating	IP20
Input Voltage	200-240V AC, 380-480V AC
