YASKAWA FS100 Option Addendum

FS100 Expanded I/O LIO-08R-B Circuit Board - Connector CN-1B
12
164104-1CD
164104-1CD
FS100
FS100 Expanded I/O LIO-08R-B Circuit Board - Connector CN-1B
CN1 Pin # CI/O Description
Signal
Type
Inform Name
159804-3
Breakout Card
Pin #
1 Input common 3 1
6 Input common 4 6
2 20150 User Input Input IN#(97) 2
27 20151 User Input Input IN#(98) 19
3 20152 User Input Input IN#(99) 3
28 20153 User Input Input IN#(100) 20
4 20154 User Input Input IN#(101) 4
29 20155 User Input Input IN#(102) 21
5 20156 User Input Input IN#(103) 5
30 20157 User Input Input IN#(104) 22
7 20160 User Input Input IN#(105) 7
32 20161 User Input Input IN#(106) 24
8 20162 User Input Input IN#(107) 8
33 20163 User Input Input IN#(108) 25
9 20164 User Input Input IN#(109) 9
34 20165 User Input Input IN#(110) 26
10 20166 User Input Input IN#(111) 10
35 20167 User Input Input IN#(112) 27
20170-7 LIO-08R Status bits Status IN#(113-120)
20180-7 LIO-08R Status bits Status IN#(121-128)
11 Input common 3_24V 11
36 Input common 4_24V 28
26 Input common 3_0V 18
31 Input common 4_0V 23
15 +24V for output load 15
22 +24V for output load 42
25 +24V for output load 48
40 +24V for output load 32
47 +24V for output load 43
12 30150 User Output Output OT#(97) 12
37 30151 User Output Output OT#(98) 29
13 30152 User Output Output OT#(99) 13
38 30153 User Output Output OT#(100) 30
16 30154 User Output Output OT#(101) 16
41 30155 User Output Output OT#(102) 33
17 30156 User Output Output OT#(103) 17
42 30157 User Output Output OT#(104) 50
19 30160 User Output Output OT#(105) 36
44 30161 User Output Output OT#(106) 37
20 30162 User Output Output OT#(107) 38
45 30163 User Output Output OT#(108) 39
23 30164 User Output Output OT#(109) 44
