YASKAWA FS100 Option Addendum

FS100 Expanded I/O LIO-08R-C Circuit Board - Connector CN2-C
14
164104-1CD
164104-1CD
FS100
FS100 Expanded I/O LIO-08R-C Circuit Board - Connector CN2-C
CN2 Pin # CI/O Description
Signal
Type
Inform Name
159804-2
Breakout Card
Pin #
1 n/a Input common 1 1
5 n/a Input common 2 5
2 20190 User Input Input IN#(129) 2
20 20191 User Input Input IN#(130) 21
3 20192 User Input Input IN#(131) 3
21 20193 User Input Input IN#(132) 22
4 20194 User Input Input IN#(133) 4
22 20195 User Input Input IN#(134) 23
6 20196 User Input Input IN#(135) 6
24 20197 User Input Input IN#(136) 25
7 20200 User Input Input IN#(137) 7
25 20201 User Input Input IN#(138) 26
8 20202 User Input Input IN#(139) 8
26 20203 User Input Input IN#(140) 27
20204 n/a n/a n/a
20205 n/a n/a n/a
20206 n/a n/a n/a
20207 n/a n/a n/a
9 n/a Input Common 1_24V 9
27 n/a Input Common 2_24V 28
19 n/a Input Common 1_0V 20
23 n/a Input Common 2_0V 24
13 n/a 24V for output load 13
16 n/a 24V for output load 16
31 n/a 24V for output load 32
10 30190 User Output Output OT#(129) 10
28 30191 User Output Output OT#(130) 29
11 30192 User Output Output OT#(131) 11
29 30193 User Output Output OT#(132) 30
14 30194 User Output Output OT#(133) 14
32 30195 User Output Output OT#(134) 33
15 30196 User Output Output OT#(135) 15
33 30197 User Output Output OT#(136) 34
17 30200 User Output Output OT#(137) 17
35 30201 User Output Output OT#(138) 36
18 30202 User Output Output OT#(139) 18
36 30203 User Output Output OT#(140) 37
30204 n/a n/a n/a
30205 n/a n/a n/a
30206 n/a n/a n/a
30207 n/a n/a n/a
