YASKAWA FS100 Option Addendum

FS100 Standard I/O LIO-08R Circuit Board - Connector CN1
6
164104-1CD
164104-1CD
FS100
FS100 Standard I/O LIO-08R Circuit Board - Connector CN1
CN1 Pin # CI/O Description
Signal
Type
Inform Name
159804-3 Break-
out Card Pin #
1 Input common 3 1
6 Input common 4 6
2 20030 User Input Input IN#(1) 2
27 20031 User Input Input IN#(2) 19
3 20032 User Input Input IN#(3) 3
28 20033 User Input Input IN#(4) 20
4 20034 User Input Input IN#(5) 4
29 20035 User Input Input IN#(6) 21
5 20036 User Input Input IN#(7) 5
30 20037 User Input Input IN#(8) 22
7 20040 User Input Input IN#(9) 7
32 20041 User Input Input IN#(10) 24
8 20042 User Input Input IN#(11) 8
33 20043 User Input Input IN#(12) 25
9 20044 User Input Input IN#(13) 9
34 20045 User Input Input IN#(14) 26
10 20046 User Input Input IN#(15) 10
35 20047 User Input Input IN#(16) 27
20050-7 LIO-08R Status bits Status IN#(17-24)
20060-7 LIO-08R Status bits Status IN#(25-32)
11 Input common 3_24V 11
36 Input common 4_24V 28
26 Input common 3_0V 18
31 Input common 4_0V 23
15 +24V for output load 15
22 +24V for output load 42
25 +24V for output load 48
40 +24V for output load 32
47 +24V for output load 43
12 30030 User Output Output OT#(1) 12
37 30031 User Output Output OT#(2) 29
13 30032 User Output Output OT#(3) 13
38 30033 User Output Output OT#(4) 30
16 30034 User Output Output OT#(5) 16
41 30035 User Output Output OT#(6) 33
17 30036 User Output Output OT#(7) 17
42 30037 User Output Output OT#(8) 50
19 30040 User Output Output OT#(9) 36
44 30041 User Output Output OT#(10) 37
20 30042 User Output Output OT#(11) 38
45 30043 User Output Output OT#(12) 39
23 30044 User Output Output OT#(13) 44
48 30045 User Output Output OT#(14) 45
