YASKAWA FS100 Option Addendum

FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-2A
8
164104-1CD
164104-1CD
FS100
FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-2A
CN2 Pin # CI/O Description
Signal
Type
Inform Name
159804-2
Breakout Card
Pin #
1 n/a Input common 1 1
5 n/a Input common 2 5
2 20070 User Input Input IN#(33) 2
20 20071 User Input Input IN#(34) 21
3 20072 User Input Input IN#(35) 3
21 20073 User Input Input IN#(36) 22
4 20074 User Input Input IN#(37) 4
22 20075 User Input Input IN#(38) 23
6 20076 User Input Input IN#(39) 6
24 20077 User Input Input IN#(40) 25
7 20080 User Input Input IN#(41) 7
25 20081 User Input Input IN#(42) 26
8 20082 User Input Input IN#(43) 8
26 20083 User Input Input IN#(44) 27
20084 n/a n/a n/a
20085 n/a n/a n/a
20086 n/a n/a n/a
20087 n/a n/a n/a
9 n/a Input Common 1_24V 9
27 n/a Input Common 2_24V 28
19 n/a Input Common 1_0V 20
23 n/a Input Common 2_0V 24
13 n/a 24V for output load 13
16 n/a 24V for output load 16
31 n/a 24V for output load 32
10 30070 User Output Output OT#(33) 10
28 30071 User Output Output OT#(34) 29
11 30072 User Output Output OT#(35) 11
29 30073 User Output Output OT#(36) 30
14 30074 User Output Output OT#(37) 14
32 30075 User Output Output OT#(38) 33
15 30076 User Output Output OT#(39) 15
33 30077 User Output Output OT#(40) 34
17 30080 User Output Output OT#(41) 17
35 30081 User Output Output OT#(42) 36
18 30082 User Output Output OT#(43) 18
36 30083 User Output Output OT#(44) 37
30084 n/a n/a n/a
30085 n/a n/a n/a
30086 n/a n/a n/a
30087 n/a n/a n/a
