YASKAWA FS100 Option Addendum

17
164104-1CD
164104-1CD
FS100
FS100 Expanded I/O LIO-08R-D Circuit Board - Connector CN2-D
FS100 Expanded I/O LIO-08R-D Circuit Board - Connector CN2-D
CN2 Pin # CI/O Description
Signal
Type
Inform Name
159804-2
Breakout Card
Pin #
1 n/a Input common 1 1
5 n/a Input common 2 5
2 20250 User Input Input IN#(177) 2
20 20251 User Input Input IN#(178) 21
3 20252 User Input Input IN#(179) 3
21 20253 User Input Input IN#(180) 22
4 20254 User Input Input IN#(181) 4
22 20255 User Input Input IN#(182) 23
6 20256 User Input Input IN#(183) 6
24 20257 User Input Input IN#(184) 25
7 20260 User Input Input IN#(185) 7
25 20261 User Input Input IN#(186) 26
8 20262 User Input Input IN#(187) 8
26 20263 User Input Input IN#(188) 27
20264 n/a n/a n/a
20265 n/a n/a n/a
20266 n/a n/a n/a
20267 n/a n/a n/a
9 n/a Input Common 1_24V 9
27 n/a Input Common 2_24V 28
19 n/a Input Common 1_0V 20
23 n/a Input Common 2_0V 24
13 n/a 24V for output load 13
16 n/a 24V for output load 16
31 n/a 24V for output load 32
10 30250 User Output Output OT#(177) 10
28 30251 User Output Output OT#(178) 29
11 30252 User Output Output OT#(179) 11
29 30253 User Output Output OT#(180) 30
14 30254 User Output Output OT#(181) 14
32 30255 User Output Output OT#(182) 33
15 30256 User Output Output OT#(183) 15
33 30257 User Output Output OT#(184) 34
17 30260 User Output Output OT#(185) 17
35 30261 User Output Output OT#(186) 36
18 30262 User Output Output OT#(187) 18
36 30263 User Output Output OT#(188) 37
30264 n/a n/a n/a
30265 n/a n/a n/a
30266 n/a n/a n/a
30267 n/a n/a n/a
