YASKAWA FS100 Option Addendum

9
164104-1CD
164104-1CD
FS100
FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-1A
FS100 Expanded I/O LIO-08R-A Circuit Board - Connector CN-1A
CN1 Pin # CI/O Description
Signal
Type
Inform Name
159804-3 Break-
out Card Pin #
1 Input common 3 1
6 Input common 4 6
2 20090 User Input Input IN#(49) 2
27 20091 User Input Input IN#(50) 19
3 20092 User Input Input IN#(51) 3
28 20093 User Input Input IN#(52) 20
4 20094 User Input Input IN#(53) 4
29 20095 User Input Input IN#(54) 21
5 20096 User Input Input IN#(55) 5
30 20097 User Input Input IN#(56) 22
7 20100 User Input Input IN#(57) 7
32 20101 User Input Input IN#(58) 24
8 20102 User Input Input IN#(59) 8
33 20103 User Input Input IN#(60) 25
9 20104 User Input Input IN#(61) 9
34 20105 User Input Input IN#(62) 26
10 20106 User Input Input IN#(63) 10
35 20107 User Input Input IN#(64) 27
20110-7 LIO-08R Status bits Status IN#(65-72)
20120-7 LIO-08R Status bits Status IN#(73-80)
11 Input common 3_24V 11
36 Input common 4_24V 28
26 Input common 3_0V 18
31 Input common 4_0V 23
15 +24V for output load 15
22 +24V for output load 42
25 +24V for output load 48
40 +24V for output load 32
47 +24V for output load 43
12 30090 User Output Output OT#(49) 12
37 30091 User Output Output OT#(50) 29
13 30092 User Output Output OT#(51) 13
38 30093 User Output Output OT#(52) 30
16 30094 User Output Output OT#(53) 16
41 30095 User Output Output OT#(54) 33
17 30096 User Output Output OT#(55) 17
42 30097 User Output Output OT#(56) 50
19 30100 User Output Output OT#(57) 36
44 30101 User Output Output OT#(58) 37
20 30102 User Output Output OT#(59) 38
45 30103 User Output Output OT#(60) 39
23 30104 User Output Output OT#(61) 44
