YASKAWA GPD515C User Manual

1-4
DRIVE TERMINAL WIRE SIZE
MODEL NO. TERMINAL SYMBOL SCREW AWG mm
2
40P41F B001 L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 2, B1, B2, T1 (U), M4 14 - 10 2 - 5.5
T2 (V), T3 (W),
40P71F B003, L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 2, B1, B2, T1 (U), M4 14 - 10 2 - 5.5
41P51F B004, T2 (V), T3 (W)
43P71F B008 M4 12 - 10 3.5 - 5.5
44P01F B011, L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 2, B1, B2, T1 (U), M4 12 - 10 3.5 - 5.5
45P51F B014 T2 (V), T3 (W),
47P51F B021 L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 2, B1, B2, T1 (U), M4 8 - 6 8 - 14
T2 (V), T3 (W),
40111F B027, L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 2, B1, B2, T1 (U), M5 8 - 6 8 - 14
40151F B034 T2 (V), T3 (W)
M6 8 8
40181F B041 L1 (R), L2 (S), L3 (T), , ⊕ 1, ⊕ 2, ⊕ 3, T1 (U), M6 6 14
T2 (V), T3 (W)
M8 8 8
l 1 (r), l 2 ( s ) M4 20 - 10 0.5 - 5.5
40221F B052 L1 (R), L2 (S), L3 (T), , ⊕ 1, ⊕ 2, ⊕ 3, T1 (U), M6 4 22
T2 (V), T3 (W)
M8 8 8
l 1 (r), l 2 ( s ) M4 20 - 10 0.5 - 5.5
40301F B065 L1 (R), L2 (S), L3 (T), , ⊕ 1, ⊕ 2, ⊕ 3, T1 (U), M8 4 22
T2 (V), T3 (W)
M8 8 8
l 1 (r), l 2 ( s ) M4 20 - 10 0.5 - 5.5
40371F B080 L1 (R), L2 (S), L3 (T), , ⊕ 1, ⊕ 2, ⊕ 3, T1 (U), M8 3 30
T2 (V), T3 (W)
M8 6 14
l 1 (r), l 2 ( s ) M4 20 - 10 0.5 - 5.5
40451F B096 L1 (R), L2 (S), L3 (T), , ⊕ 1, ⊕ 2, ⊕ 3, T1 (U), M8 1 50
T2 (V), T3 (W)
M8 6 14
l 1 (r), l 2 ( s ) M4 20 - 10 0.5 - 5.5
40551F B128 L1 (R), L2 (S), L3 (T), T1 (U), T2 (V), T3 (W) M10 4/0 100
, ⊕ 3, M8 4 22
l 1 (r), l 2 200 ( s 200), l 2 400 ( s 400) M4 20 - 10 0.5 - 5.5
40750F B165 L1 (R), L2 (S), L3 (T), T1 (U), T2 (V), T3 (W) M10 1/0 x 2P 60 x 2P
, ⊕ 3, M8 4 22
l 1 (r), l 2 200 ( s 200), l 2 400 ( s 400) M4 20 - 10 0.5 - 5.5
41100F B224 L1 (R), L2 (S), L3 (T), T1 (U), T2 (V), T3 (W) M10 1/0 x 2P 60 x 2P
, ⊕ 3, M8 3 30
l 1 (r), l 2 200 ( s 200), l 2 400 ( s 400) M4 20 - 10 0.5 - 5.5
41600F B302 L1 (R), L2 (S), L3 (T), T1 (U), T2 (V), T3 (W) M12 4/0 x 2P 100 x 2P
, ⊕ 3, M8 1 50
l 1 (r), l 2 200 ( s 200), l 2 400 ( s 400) M4 20 - 10 0.5 - 5.5
41850F B340, L1 (R), L2 (S), L3 (T), , ⊕1, ⊕ 3, T1 (U), T2 (V), M16
MCM650 x 2P 325 x 2P
42200F B450, T3 (W)
43000F B605 M8 1/0 60
l 1 (r), l 2 200 ( s 200), l 2 400 ( s 400) M4 20 - 10 0.5 - 5.5
Section B. 460V
NEW DRIVE OLD DRIVE
TERMINAL
WIRE SIZE
MODEL NO. MODEL NO.
TERMINAL SYMBOL
CIMR-G5M GPD515C–
SCREW
AWG mm
2
Table 1-1. Typical Wire Sizing For Main Circuit - Continued*
* Consult local electrical codes for wire sizing requirements.
