3.2 Function Modules
Data Logging
3-73
3
CPU Unit Functionality
 Select whether to add date information to the folder name.
• To omit date information, clear the selection of the check box.
• To add date information, select the check box and select the date format from the list.
6. Click the OK Button.
The Format Dialog Box closes.
7. Click the File output Button in the Logging 1 Dialog Box.
The File Output Dialog Box will be displayed.
8. Set the file output settings.
Set the number of output files.
*1
• Settings: No restriction
*2
, 1, 10, 50, 100, 500, or 1,000
*1. This is the total number of files that are created from when the power supply is turned ON to when it is
turned OFF.
*2. If the built-in RAM disk is the storage location, the upper limit is 4,000 files.
If the USB memory device is the storage location, the upper limit is 10,000 files.
Setting Description
Year (YYYY)
Adds the year to the specified folder name.
Example: 2011
Year/Month
(YYYYMM)
Adds the year and month to the specified folder name.
Example: 201109
Year/Month/Day
(YYYYMMDD)
Adds the year, month, and day to the specified folder name.
Example: 20110920
Year/Month/Day/Hour
(YYYYMMDDHH)
Adds the year, month, and day to the specified folder name and creates another
folder directly below it named with the hour.
Example: 20110920
12 The sampled data is stored in this folder.
Click the Cancel Button to return to the Logging 1 Dialog Box without registering the set-
tings.
Information


